Our Metalized BOPET Laminating Film is a revolutionary product for all your thermal film laminating needs. It is designed to withstand high temperatures without compromising on the clarity and quality of your laminated documents. This product is perfect for industries that require high-temperature lamination, such as automotive, aerospace, and electronic industries.
|
Physical and Mechanical Properties |
||||
|
Item Name |
Standard |
Typical |
Testing |
|
|
Tensile Strength Mpa |
MD |
≥35 |
64 |
ASTM D638 |
|
TD |
≥25 |
32 |
||
|
Elongation at break % |
MD |
≥280 |
650 |
|
|
TD |
≥380 |
750 |
||
|
Haze % |
Thickness≤30μm |
≤5.0 |
≤2.3 |
ASTM D1003 |
|
30μm<Thickness<80μm |
≤8.0 |
≤4.5 |
||
|
Heat Sealing Temperature ℃ |
Heat Sealing Type |
<145 |
122(≥8N) |
/ |
|
Non-heat Sealing Type |
≥145 |
/ |
/ |
|
|
Surface Tension dyn/cm |
Treatment Surface |
≥380 |
≥38 |
ISO 8296 |
|
Non-treatment Surface |
<33 |
/ |
||
|
Dynamic Friction Coefficient |
/ |
/ |
0.65-0.75 |
ASTM D1984 |
BOPET polyester film, the thickness of products ranges from 1.2 to 25 wires, depending on the thickness, the number of meters per roll is also different. Each roll is made of 46 mm inner diameter paper tube wrapped with bubble film.
Can the width of each roll be arranged according to the customer's requirements, and the large demand can be made with 3 wooden pallets (under normal circumstances, one pallet for every 9 pieces)
Our Metalized BOPET Laminating Film is made of high-quality materials that ensure durability, strength, and high-temperature resilience. The following are some of the features that make our product stand out from the competition.
1. High-temperature resistance: Our product can withstand temperatures of up to 180 °C, meaning it can be used in high-temperature environments without degrading or compromising its quality.
2. Excellent clarity: Our film's high clarity ensures that your documents remain legible and bright after lamination, giving your images a star-quality finish.
3. Superior adhesion: Our Metalized BOPET Laminating Film has excellent adhesion properties, providing a strong bond to the substrate, thus ensuring long-lasting protection.
4. Environmentally friendly: Our product is made with environmentally friendly materials, making it safe for you and the environment.
Our Metalized BOPET Laminating Film is a must-have lamination option for industries that require a strong, durable, and high-quality lamination finish. Whether you are in the automotive, aerospace, or electronics industry, our product is the perfect choice for high-temperature applications. Choose our film for superior protection, better quality, and increased durability.
