PA Adhesive Film is an adhesive material made from polyamide or nylon. Its main function is to adhere two surfaces together and ensure that they remain securely in place. The film is applied by using heat and pressure to activate the adhesive properties. PA Adhesive Film is available in various thicknesses and comes with different adhesive strengths.
|
Physical and Mechanical Properties |
||||
|
Item Name |
Standard |
Typical |
Testing |
|
|
Tensile Strength Mpa |
MD |
≥35 |
64 |
ASTM D638 |
|
TD |
≥25 |
32 |
||
|
Elongation at break % |
MD |
≥280 |
650 |
|
|
TD |
≥380 |
750 |
||
|
Haze % |
Thickness≤30μm |
≤5.0 |
≤2.3 |
ASTM D1003 |
|
30μm<Thickness<80μm |
≤8.0 |
≤4.5 |
||
|
Heat Sealing Temperature ℃ |
Heat Sealing Type |
<145 |
122(≥8N) |
/ |
|
Non-heat Sealing Type |
≥145 |
/ |
/ |
|
|
Surface Tension dyn/cm |
Treatment Surface |
≥380 |
≥38 |
ISO 8296 |
|
Non-treatment Surface |
<33 |
/ |
||
|
Dynamic Friction Coefficient |
/ |
/ |
0.65-0.75 |
ASTM D1984 |
Benefits of Using PA Adhesive Film in Manufacturing
1. Versatility
PA Adhesive Film is highly versatile, making it suitable for use in multiple industries and manufacturing applications. It adheres well to various types of surfaces, including metal, plastic, wood, and glass. This versatility makes it an excellent choice for assembly, lamination, and sealing applications.
2. Strength and Durability
PA Adhesive Film provides reliable bonding and is known for its exceptional strength and durability. It can withstand harsh environmental conditions, such as extreme temperatures and humidity. This makes it ideal for use in industries like aerospace, automotive, and electronics, where high-stress environments are common.
3. Cost-Effective
PA Adhesive Film is a cost-effective solution for manufacturing needs. It is easy to apply, reducing the amount of time and labor required for production. Additionally, the material is available in bulk quantities, which makes it more affordable than some other adhesive options.
4. Customizable
PA Adhesive Film is available in a range of adhesive strengths, thicknesses, and widths. This customizability makes it easy to find the perfect fit for any manufacturing application. Additionally, it can be used alongside other adhesive materials, such as tapes and gels, to provide even stronger bonding solutions.
5. Environmentally Friendly
PA Adhesive Film is an environmentally friendly option, making it the ideal choice for businesses looking to reduce their carbon footprint. It is free from harmful chemicals and does not require any solvents or other hazardous materials to apply. Additionally, the material is recyclable, reducing waste and promoting a sustainable manufacturing process.
