Wenzhou Jincheng Plastic Products Co., Ltd.
Wenzhou Jincheng Plastic Products Co., Ltd.
Products
BOPET Heat Seal Film
  • BOPET Heat Seal FilmBOPET Heat Seal Film
  • BOPET Heat Seal FilmBOPET Heat Seal Film
  • BOPET Heat Seal FilmBOPET Heat Seal Film
  • BOPET Heat Seal FilmBOPET Heat Seal Film
  • BOPET Heat Seal FilmBOPET Heat Seal Film

BOPET Heat Seal Film

One of the significant advantages of BOPET Heat Seal Film is its high strength and durability, making it suitable for packaging a wide range of products.

One of the significant advantages of BOPET Heat Seal Film is its high strength and durability, making it suitable for packaging a wide range of products.  The film's resistance to tearing and puncturing minimizes the chances of the packaged product getting damaged during transit or storage.  Moreover, the film's excellent clarity and gloss make the product appealing to the consumers.



BOPET Heat Seal FilmBOPET Heat Seal Film

Product Parameter (Specification)



Physical and Mechanical Properties

Item Name

Standard
Value

Typical
Index

Testing
Standard

Tensile Strength Mpa

MD

≥35

64

ASTM D638

TD

≥25

32

Elongation at break %

MD

≥280

650

TD

≥380

750

Haze %

Thickness≤30μm

≤5.0

≤2.3

ASTM D1003

30μm<Thickness<80μm

≤8.0

≤4.5

Heat Sealing Temperature ℃

Heat Sealing Type

<145

122(≥8N)

/

Non-heat Sealing Type

≥145

/

/

Surface Tension dyn/cm

Treatment Surface

≥380

≥38

ISO 8296

Non-treatment Surface

<33

/

Dynamic Friction Coefficient

/

/

0.65-0.75

ASTM D1984



BOPET polyester film, the thickness of products ranges from 1.2 to 25 wires, depending on the thickness, the number of meters per roll is also different.  Each roll is made of 46 mm inner diameter paper tube wrapped with bubble film.



Can the width of each roll be arranged according to the customer's requirements, and the large demand can be made with 3 wooden pallets (under normal circumstances, one pallet for every 9 pieces)



BOPET Heat Seal FilmBOPET Heat Seal Film



Product Feature And Application



Single-sided heat sealing Film, after printing the pattern on the non-heat sealing layer, is compounded with PE, BOPP and aluminum foil to make bags, which is used for food, tea, beverages and other packaging. Double-sided heat sealing Film directly heat seals and forms packaging food, textiles, audio and video products, poker, etc. All of these require the Film to have good heat sealing properties.



BOPET Heat Seal Film

Product Details



Another significant advantage of BOPET Heat Seal Film is its ability to withstand high temperatures.  The film can withstand temperatures of up to 200°C, making it suitable for packaging products that require high-temperature sealing or sterilization.  Additionally, the film's excellent barrier properties make it ideal for packaging products that require protection against moisture, oxygen, and other environmental factors.





Hot Tags: BOPET Heat Seal Film, China, Manufacturer, Supplier, Factory
